Displacement sensor
LF25 series
Key words:
LF25 series
Related downloads :
- Description
- Specs
- Model
-
- Commodity name: LF25 series
- Commodity ID: LF25
- Category: Displacement sensor
- Model No.: LF25
LF25 series displacement sensors use laser technology for measurement which is mainly used for contactless measurement of changes in the position, displacement, etc. of objects. It consists of a laser, a laser detector, and a measurement circuit, which can accurately measure the geometric quantities of the measured object, such as displacement, thickness, vibration, distance, and diameter. We supply various sizes and specifications with product width from 25mm, 44mm, 60mm, to 90mm for customers to select according to installation ambient.
Laser displacement sensor is a sensor that uses laser technology for measurement. It consists of a laser, a laser detector, and a measurement circuit. Laser sensors are a new type of measuring instrument. Capable of accurately non-contact measurement of changes in the position, displacement, etc. of the object being measured.
It can measure precise geometric measurements such as displacement, thickness, vibration, distance, diameter, etc. Laser has the excellent characteristic of good straightness, and similarly, laser displacement sensors have higher accuracy compared to known ultrasonic sensors. -
● Small light spot and high precision
● Equipped with dual outputs of switch and analog signals
● Multiple detection distances, diverse models
● Digital display screen, clear and bright
● Aluminum alloy shell, sturdy and durableGeneral Parameters
Parameters Type AC/DC 2 wires DC 2 wires Model IMC30-10BU□ IMC30-15NU□ IME30-16BU□ IME30-25NU□ IMC30-10BD□ IMC30-15ND□ IME30-16BD□ IME30-25ND□ IMC30-10BU□-T3 IMC30-15NU□-T3 IME30-16BU□-T3 IME30-25NU□-T3 IMC30-10BD□-T3 IMC30-15ND□-T3 IME30-16BD□-T3 IME30-25ND□-T3 Installation mode Flush Non-flush Flush Non-flush Flush Non-flush Flush Non-flush Sensing distance 10mm 15mm 16mm 25mm 10mm 15mm 16mm 25mm Hysteresis ＜15%of the sensing distance Switch frequency 25Hz AC；40Hz DC 300Hz 150Hz 300Hz 150Hz Electrical Parameters Supply voltage 20~250V AC /20~250V DC 10~30VDC Voltage drop Max.10 VAC；8 VDC ≤4.5V Circuit protection Over voltage protection Reverse polarity protection, short circuit protection, over voltage protection Load current 200mA Repetitive accuracy <1%（ Sr） Operation mode Normally open(NO), normally closed(NC) Indication light Yellow light Insulation resistance Min.50MΩ（ 500VDC/1000VDC） Dielectric strength 500VAC ，1min， between electrical appliances and housing Mechanical Parameters Size Refer to drawing Housing material Copper with nickel plating surface Sensing surface Material: PBT Cable Direct outlet, anti-oil PVC cable,wire length 2m; Optional M12 connector Cable diameter Φ5mm Cable cross section 3*0.34mm² Screw size M30 Environmental Parameters Ambient temperature -25~70℃（ no freezing, no condensation） Vibration resistance 10~55HZ(1.5mm amplitude for 2 hours each in X,Y,Z directions) (when outage) Protection rating IP67 Dimensional diagram
-
Type Distance Type Installation Mode Sensing Distance Cable Type Output Type Product Model AC/DC 2 wires Standard Distance Flush 10mm Direct outlet DC/AC-NO IMC30-10BUO-P DC/AC-NC IMC30-10BUC-P M12 connector DC/AC-NO IMC30-10BUO-T3-P DC/AC-NC IMC30-10BUC-T3-P Non-flush 15mm Direct outlet DC/AC-NO IMC30-15NUO-P DC/AC-NC IMC30-15NUC-P M12 connector DC/AC-NO IMC30-15NUO-T3-P DC/AC-NC IMC30-15NUC-T3-P Double Distance Flush 16mm Direct outlet DC/AC-NO IME30-16BUO-P DC/AC-NC IME30-16BUC-P M12 connector DC/AC-NO IME30-16BUO-T3-P DC/AC-NC IME30-16BUC-T3-P Non-flush 25mm Direct outlet DC/AC-NO IME30-25NUO-P DC/AC-NC IME30-25NUC-P M12 connector DC/AC-NO IME30-25NUO-T3-P DC/AC-NC IME30-25NUC-T3-P DC 2 wires Standard Distance Flush 10mm Direct outlet DC-NO IMC30-10BDO-P DC-NC IMC30-10BDC-P M12 connector DC-NO IMC30-10BDO-T3-P DC-NC IMC30-10BDC-T3-P Non-flush 15mm Direct outlet DC-NO IMC30-15NDO-P DC-NC IMC30-15NDC-P M12 connector DC-NO IMC30-15NDO-T3-P DC-NC IMC30-15NDC-T3-P Double Distance Flush 16mm Direct outlet DC-NO IME30-16BDO-P DC-NC IME30-16BDC-P M12 connector DC-NO IME30-16BDO-T3-P DC-NC IME30-16BDC-T3-P Non-flush 25mm Direct outlet DC-NO IME30-25NDO-P DC-NC IME30-25NDC-P M12 connector DC-NO IME30-25NDO-T3-P DC-NC IME30-25NDC-T3-P
